Behringer XENYX 502S Analog 5-Input Mixer with USB Streaming Interface

The ultra-compact XENYX 502S mixer’s 5 inputs allow you to effortlessly achieve premium-quality sound that’s perfect for streaming, podcasting and recording. It provides a warm and ultra-musical sound thanks to its award-winning XENYX microphone preamp.

Features:

-Ultra-low noise analog mixer for streaming, podcasting and recording
-Award winning XENYX microphone preamp for warm and musical sound
-Stereo USB audio interface to connect to your computer or mobile device
-Direct mixing of PC/gaming sounds into the streaming output
-Analog mixing and equalization for pure sound
-Versatile sub mixer for network enabled audio devices
-Stereo channel 4/5 automatically switches between TRS input and USB playback
-High-quality main, phones and streaming outputs
-Stereo RCA inputs assignable to main mix or monitor/phones outputs

Specifications:

 Mono Inputs
Microphone Input:
-Balanced XLR, discrete input circuit
-Mic EIN (22 Hz-22 kHz) @ 50 Ω: 132 dB, A-weighted
-Frequency response Gain +10 dB: 10 Hz to 150 kHz
-Frequency response Gain +60 dB: 20 Hz to 70 kHz
-Gain range: +10 dB to +60 dB
-Max input level @ +10 dB Gain: +12 dBu
-Input Impedance: 2 kΩ balanced
-Distortion (THD + N) 1 kHz @ +10 dB Gain: 0.005%

Mono Line Inputs:
-1/4" TRS connector balanced
-Impedance: 22 kΩ balanced, 10 kΩ unbalanced
-Gain range: -10 dB to +40 dB
-Max input level @ 0 dB Gain: +21 dBu

 Stereo Inputs
Stereo Line:
-1/4" TRS connector balanced
-Frequency response: 20 Hz to 200 kHz
-Impedance: 22 kΩ balanced, 10 kΩ unbalanced
-Max input level @ 0 dB Gain: +21 dBu

STREAM Inputs (Analog):
-RCA connector unbalanced
-Impedance: 10 kΩ unbalanced
-Max input level: 10 dBu

EQUALIZER
-Low: 80 Hz/±15 dB
-High: 12 kHz/±15 dB

Main, Monitor & FX Send Outputs
-Type: 1/4" TRS connector impedance-balanced
-Impedance: 120 Ω
-Max output level: 21 dBu

Phones Out
-Type: 1/4" TRS connector unbalanced
-Impedance: 23 Ω
-Max output level: 19 dBu/150 Ω

STREAM out (Analog)
-Type: RCA connector unbalanced
-Impedance: 1 kΩ unbalanced
-Max output level: 10 dBu

Main Mix noise
-Main Mix @ -∞: -109 dBu A-weighted
-Channel @ -∞: -109 dBu A-weighted

USB
-Type: Type-B connector
-USB Audio Data: 48 kHz 16 bit
-UAC2 Class Compliant: stereo in/out

Power Supply
-Power Consumption: 8 W
-Adaptor input: 100 - 240 V~, 50/60 Hz, 0.5 A
-Adaptor output: 18 V DC 1.0 A
